Overview

Before even starting as a Developer of the Tevico Community project, you should start understanding the basics of its vision and the workflow. This will give you a deeper understanding of the project and align your code logic with the expected outcome.

Project Vision

The vision of the project can be broken down into a simple statement -

"Leverage Tevico to gain actionable insights in a secure way and enhance infrastructure efficiency."

Let us try to break down this vision in 3 parts -

  1. Actionable Insights - Deep set of insights into the infrastructure of its user
  2. Secure Way - Collect these insights in a secure way
  3. Infrastructure Efficiency - Guide its user to improve the efficiency of its infrastructure

Once this philosophy is clear you can proceed with understanding its workflow.

Project Workflow

The project workflow provides a birds-eye view on the question of "How Tevico Community works?".

1. The main Command

The main command is the entry point of this project. Before even initiating the framework, the main command parses the CLI params, accordingly initiates the TevicoConfig object and runs the required set of functions to either run the project or create entities. As the arguments are parsed the config is passed to the Framework Handler.

2. Framework Handler

Think of the FrameworkHandler as a wrapper around the framework itself. It encapsulates and abstracts the configuration from the TevicoFramework and depending on the command given in the CLI param it executes the framework.

3. Framework

The Framework executes the following sequence of actions for the run command -

  1. Load the providers
  2. For every provider, establish connection
  3. Start execution
  4. Collect all check responses
  5. Generate report

4. Report

The report will be generated in a .zip format in the AWS CloudShell. You can follow the steps given in the Get Started -> Download report section of this documentation to download the report.

Once you have extracted the report you can explore the report in 3 ways -

  1. Overview - An aggregated or a bird's eye view of the infra
  2. Browse - Browse by filtering through the checks
  3. Well-Architected Review - An overall understanding of WAR in your infra

The diagram given below shows the workflow for the run command.

Workflow
